Hydraulic filter elements are the core protective components of hydraulic systems. They effectively remove dust, rust, and wear particles, maintain fluid cleanliness, extend the service life of key components such as pumps and valves, and ensure long-term stable system operation.
Filter media directly determines filtration precision, service life, and maintenance method. Please select the appropriate material based on your application requirements.
| Material | Filtration Precision | Dirt-Holding Capacity | Service Life | Cleanable | Recommended Applications |
|---|---|---|---|---|---|
| Wire Mesh | Coarse (>40μm) | Low | Long | ✅Cleanable | Suction filtration, coarse filtration |
| Cellulose Paper | Moderate | Medium | Short | ❌Not | Economical disposable filtration |
| Fiberglass | Fine (3~10μm) | High | Long | ❌Not | Recommended-High-pressure/ servo systems |
| Stainless Steel Fiber | Fine (3~10μm) | High | Long | ✅Cleanable | High-temperature/corrosive environments |
Different hydraulic systems have varying cleanliness requirements. Choose according to your system type.
| Grade | Precision | Typical Applications |
|---|---|---|
| Coarse | >40μm | Suction lines |
| Medium | 10~40μm | Return lines |
| Fine | 3~10μm | High-pressure / standard servo |
| Ultra-Fine | 1~3μm | Proportional / precision servo |
Our products are compatible with a wide range of hydraulic fluids and serve as direct OEM replacements with comparable performance. Wire mesh and stainless steel fiber elements can be cleaned with industrial fluid and reused. Cellulose and fiberglass elements require regular replacement based on operating conditions. Regular maintenance prevents valve sticking, pump wear, and system failures, ensuring optimal performance under heavy-duty conditions.
| R928005961 1.0400 H3XL-A00-0-M |
R928019790 1.0630 H1XL-A00-0-M | R928007133 2.0059 PWR10-A00-6-M | R928005711 1.0095 H10XL-A00-0-M |
| R928006888 2.0250 H3XL-A00-0-V | R928017210 9.160LA H10XL-A000-M | R928017783 17.70H10XL-G00-5-M | R928017867 17.120 H3XL-G00-5-M |
| R928019019 18.519C P10-S00-0-0 | R928048397 10063AS6-A00-O-M | R900229752 ABZFE-N0160-10-1X/M-A | R928016621 7.004 P10-S00-0-M |
| R928045319 1.901 G60-A00-0-M | R928005638 1.0045 PWR6-A00-0-M | R928005639 1.0045H10XL-A00-0-M | R928035131 1.0055 H6XL-A00-0-M |
Q: Are you a manufacturer?
A: Yes, we are a factory-direct supplier.
Q: What types of filter elements do you manufacture?
A: We produce a wide range of filter elements, including hydraulic filters, air filters, air compressor filters, water filters, sintered stainless steel filters, as well as oil purifiers and related equipment.
Q: Do you offer custom filter elements?
A: Yes, we support OEM and ODM services. We can design filter elements to meet your requirements based on specified size, material, and structure, or manufacture according to your drawings.
Q: What is your production lead time?
A: For samples or small orders, it typically takes 5–7 working days; for bulk orders, it is generally 12–15 working days.
Q: What is your warranty period?
A: Our standard warranty period is 12 months. This means under normal installation and use. In this case, if quality issues arise, we will reproduce the product free of charge.
Q: What are your shipping methods?
A: We support express shipping (DHL/FEDEX/UPS), air freight, and sea freight. If you have a long-term freight forwarding partner, we can arrange delivery to their warehouse.
